Designed for leak detection in lubricant and hydraulic systems, including hydraulic oil, compressor oil, engine oil, gearbox oil, gasoline, and diesel fuel systems.
Used in facility maintenance, machinery, mobile and stationary hydraulic equipment, and OEM in-line quality control.
Available Sizes & Part Numbers
Old Part #
Part #
Description
OIL-GLO 45-P
SPI-OGB-16
16 oz. (473 ml) bottle, for all oil-based fluids
OIL-GLO 45-Q
SPI-OGB-32
32 oz. (946 ml) bottle, for all oil-based fluids
OIL-GLO 45-G
SPI-OGB-1G
1 gallon (4 L) container, for all oil-based fluids
OIL-GLO 45-5G
SPI-OGB-5G
5 gallon (19 L) container, for all oil-based fluids
OIL-GLO 45-D
SPI-OGB-55G
55 gallon (208 L) drum, for all oil-based fluids
Dosage Chart by Fluorescent Dye Color
Recommended starting ratios for dye-to-fluid dilution.
Dye Color
Dilution Ratio
Dilution Ratio (%)
Blue, Green, Yellow-Green
1 fl oz (30 mL) treats up to 25 gal (94 L)
Up to 0.031%
Yellow, White
1 fl oz (30 mL ) treats up to 30 gal (113 L)
Up to 0.026%
Dosage notes: Dosage ratios are guidelines and may vary based on fluid condition, fluid color, lighting, and inspection lamp strength. Darker or naturally fluorescent fluids may require additional UV dye or a different fluorescent dye color to achieve the desired glow.
